Cranfield DrivAer] CAD_Pack_1 Main Body
Date published
2018-04-10 16:30
Free to read from
Supervisor/s
Journal Title
Journal ISSN
Volume Title
Publisher
Cranfield University
Department
Type
Dataset
ISSN
Format
Citation
Soares, Renan francisco; Garry, Kevin; Holt, Jenny (2018). [Cranfield DrivAer] CAD_Pack_1 Main Body. Cranfield Online Research Data (CORD). Dataset. https://doi.org/10.17862/cranfield.rd.6086624
Abstract
Main Body CAD Pack (35% scaled-version), including:1. DrivAer_hp - Main_body (S):Main-body surface, with two cuttings for Rear-end and Diffuser CAD Pack.2. DrivAer_hp - Main_body (S) (diffuser lid):'Diffuser lid' surface, which matches the Main-body's Diffuser cutting in order to complete the Main-body, smooth underfloor version (S).CAD files available in IGS, STEP, STL, and Parasolid formats. All geometries are provided in [mm].Notation:(S) = [modified] Smooth Underfloor CAD designed and uploaded by:Renan F Soares - PhD in Aerospace Applied Aerodynamics Group Cranfield University, United Kingdom
Description
Software Description
Software Language
Github
Keywords
CAD', 'DrivAer', 'Automotive', 'Aerodynamics', 'Vehicle', 'Automotive Engineering not elsewhere classified', 'Aerodynamics (excl. Hypersonic Aerodynamics)'
DOI
10.17862/cranfield.rd.6086624
Rights
CC BY 4.0
Relationships
Relationships
Funder/s
CNPq (Brazilian National Council for Scientific and Technological Development)
